4 Bed 4.5 Bath
2939 Sq. Ft. - Haddies Hideaway- All Suites
2939 Sq. Ft. - Haddies Hideaway- All Suites
To learn more about what's included with our plans Click here
Would you like to modify this plan? Submit a request form here
Plan Description
Sq Ft. - 2939 | Bed - 4 | Bath - 4.5 | Stories - 2 | Cars - 2
At under 3000 square feet, you can enjoy plenty of living and private spaces with this plan. Haddie's Hideaway- "All Suites" has 2 primary suites- one on the main level and one upstairs. Take advantage of views from any side of the house. An open floor plan with a large kitchen island is perfect for families and friends. A small office with a built-in desk off the living room allows for a more private workspace when needed without using up excess floor space and allowing for true guest rooms or dens. Each bedroom has a private bathroom and the upstairs sitting room has a coffee bar- perfect for lounging at the start or end of the day. As an elevated plan, this house has 2 front loader garages that blend into the ground-floor louver aesthetic.
Dimensions: Width: 40'0" | Depth: 56' 0" | Max Ridge Height: 36' 9"
Exterior Walls: 2x6
Ceiling Height: Lower Level: 9' | First Floor: 9' | Second Floor: 9'
Foundation Type: Piling
Roof Details: Primary Pitch: 4 on 12| Secondary Pitch: 3 on 12 | Framing Type: Truss
Garage: Type: Attached, Drive Under | Area: 975 sq. ft. | 2 Cars | Front Entry
