Winthrop Studio
Studio Garage Apartment ADU | Vaulted Ceilings & Outdoor Deck
576 Sq Ft | 0 Bed | 1.0 Bath | 2-Story
430+ Plans Sold · Lowest Price Guaranteed.
Buy direct & save 5% vs. marketplaces. Price match policy →
Licensed for one build at your build address.
Would you like to customize this plan? Request a free modification quote.
Modify This PlanWinthrop Studio Garage/ADU Plan
Studio Garage Apartment ADU Plan
576 SQ. FT. | STUDIO | 1 BATH | 2-STORY | 2-CAR GARAGE
The Winthrop Studio is a 576 square foot studio apartment over a two-car garage, one open room under a vaulted ceiling with a kitchenette, a full bath and a deck of its own at the top of the stairs.
It is the simplest plan in our garage apartments and the most flexible: a rental, a guest room, an office, a studio for someone who paints or plays. The garage below keeps its two bays for the main house.
A vaulted ceiling: the ceiling follows the roof over the studio, so one room feels like a bigger one.
A private deck: the stair lands on a deck that belongs to the studio, for coffee in the morning or a chair in the evening.
A kitchenette: enough kitchen to cook and clean up, for daily living or a short-term guest.
One room, many uses: apartment, guest suite, office or workshop for the creative side of the family.
A two-car garage: parking for two and storage at ground level.
- Footprint: 28’ 4” Width x 24’ 0” Depth
- Max Ridge Height: 25’ 0”
- Foundation: Slab on Grade
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 9’ First Floor | 8’ Second Floor
- Garage: 576 sq. ft., 2 Cars, Front Entry
- Roof Details: 6 on 12 Primary / 10 on 12 Secondary Pitch | Truss Framing
The Winthrop Studio shows that a studio need not feel small: a vaulted ceiling, a private deck and an open plan make one room live like more.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations (most plans; please inquire to confirm)
What's not included
- Architectural or engineering stamp: handled locally if required
- Site plan: handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work): your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations): your subcontractors handle this
- Energy calculations: handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for Chief Architect X17 or Home Designer Pro 2023 or newer
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does Winthrop Studio come with?
Winthrop Studio is drawn on a slab on grade foundation. A local engineer sizes the foundation for your soil and wind zone.
How tall is Winthrop Studio and how much ground does it cover?
The maximum ridge height is 25' 0". The footprint is 28' 4" x 24' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 576 square feet on 2 stories.
What comes in the plan set for Winthrop Studio, and what do I still need locally?
A licensed construction set: cover sheet with general notes, foundation plan, dimensioned floor plans for every level, all four exterior elevations, a cross section, roof plan, electrical plans, and door and window schedules, sold as PDF, PDF plus CAD, or Chief Architect files. Every set is licensed for one build at your build address. An engineer's review and stamp where required, a site plan, engineered floor and roof framing, mechanical and plumbing drawings and energy compliance are produced locally, as they are for any stock plan.
