Cloudy Bay
Low Country Coastal | Timber Frame Gables & Metal Roof
2730 Sq Ft | 4 Bed | 4.0 Bath | 2-Story
430+ Plans Sold · Lowest Price Guaranteed.
Buy direct & save 5% vs. marketplaces. Price match policy →
Licensed for one build at your build address.
Would you like to customize this plan? Request a free modification quote.
Modify This PlanThe Cloudy Bay House Plan
4-Bedroom Low Country Residence
2,730 SQ. FT. | 4 BED | 4 BATH | 2-STORY | 2-CAR DETACHED
The Cloudy Bay is a showstopping low country house blueprint designed to make an unforgettable first impression. Striking timber-framed gables, a standing seam metal roof, and a crisp, refined exterior layout set a high-end architectural tone before you even cross the threshold.
Once inside, interior exposed beams carry that rich structural character seamlessly through the open-concept living and kitchen areas. Featuring three private upper-level en-suite bedrooms and a master wing complete with an exclusive private sun deck, this layout perfectly marries grand-scale design statements with warm, effortless livability.
Striking Low Country Facade: Timber-framed gables and a metal roof deliver bold, premium curb appeal that excels on any coastal or infill lot.
Exposed Beam Character: Structural timber accents run through the primary living and dining zones, adding incredible warmth and visual cohesion.
Three Private En-Suite Retreats: Every single secondary upstairs bedroom features its own dedicated, private full bathroom—ideal for large families or luxury vacation rentals.
Master Wing with Private Sun Deck: The primary suite crowns the upper level, boasting exclusive access to an elevated sun deck for quiet morning coffee or sunsets.
Detached 2-Car Garage: A separate, matching 600 sq. ft. front-entry garage keeps the main home’s front profile perfectly clean and architecturally pure.
- Footprint: 34’ 0” Width x 65’ 0” Depth (designed beautifully for narrow coastal or standard infill lots)
- Max Ridge Height: 31’ 6”
- Foundation: Cost-efficient Slab on Grade
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: Grand 10’ First Floor | 9’ Second Floor
- Garage: Detached 2-Car Front Entry (600 sq. ft.)
- Roof Details: Steep 10 on 12 Pitch | Truss Framing
Every blueprint in our collection is crafted with a strict focus on structural flow and spatial efficiency. Cloudy Bay delivers the rare, coveted combination of an aggressive architectural exterior profile and a highly functional, zero-waste interior—proving that a premier design statement can also serve as an effortlessly livable everyday home.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue and studies in interior architecture.
With 16+ years of custom home design—including a decade in custom construction in Charleston, SC—Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations — most plans, please inquire to confirm
What's not included
- Architectural or engineering stamp — handled locally if required
- Site plan — handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work) — your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations) — your subcontractors handle this
- Energy calculations — handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for Chief Architect X17 or Home Designer Pro 2023 or newer
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does Cloudy Bay come with?
Cloudy Bay is drawn on a slab on grade foundation. A local engineer sizes the foundation for your soil and wind zone.
How tall is Cloudy Bay and how much ground does it cover?
The maximum ridge height is 31' 6". The footprint is 34' 0" x 65' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 2,730 square feet on 2 stories.
What comes in the plan set for Cloudy Bay, and what do I still need locally?
A licensed construction set: cover sheet with general notes, foundation plan, dimensioned floor plans for every level, all four exterior elevations, a cross section, roof plan, electrical plans, and door and window schedules, sold as PDF, PDF plus CAD, or Chief Architect files. Every set is licensed for one build at your build address. An engineer's review and stamp where required, a site plan, engineered floor and roof framing, mechanical and plumbing drawings and energy compliance are produced locally, as they are for any stock plan.
Can I look at Cloudy Bay in detail before buying the full set?
Yes. A $75 study set of Cloudy Bay includes dimensioned floor plans for every level, all four elevations, door and window schedules and a specification sheet, enough to hand a builder for a budget number and to check the footprint against your lot. It is not licensed for construction. The $75 credits in full toward the Cloudy Bay construction set for twelve months.
