Haddie's Hideaway All Suites
Dual Primary Suite Coastal | Elevated Piling/Pier Foundation
2939 Sq Ft | 4 Bed | 4.5 Bath | 2-Story
430+ Plans Sold · Lowest Price Guaranteed.
Buy direct & save 5% vs. marketplaces. Price match policy →
Licensed for one build at your build address.
Would you like to customize this plan? Request a free modification quote.
Modify This PlanHaddie's Hideaway All Suites House Plan
4-Bedroom Coastal Plan with Two Primary Suites
2,939 SQ. FT. | 4 BED | 4.5 BATH | 2-STORY
Haddie's Hideaway All Suites gives every bedroom its own bath, and two of them are full primary suites: one on the main living floor and one upstairs. It is drawn for two generations under one roof, or for a rental where nobody shares a bathroom, in just under 3,000 square feet.
Upstairs there is a sitting room with a coffee bar, so the morning can start without going down to the kitchen. On the main floor a built-in desk sits in a nook off the great room, and the kitchen is open and sized for a crowd. The house stands on pilings over a two-car, front-entry garage that hides behind louvers, so the ground floor reads as part of the house rather than a garage door.
Two primary suites: one on the main floor and one upstairs, each a full suite, for parents and grandparents, for two couples, or for a rental with two top bedrooms instead of one.
A bath for every bedroom: all four bedrooms are suites with their own bathrooms, so guests never wait in a hallway.
A coffee bar upstairs: a second-floor sitting room with a built-in beverage bar, a quiet place for the first cup before the house wakes up.
A desk that is not a bedroom: a built-in office nook just off the great room keeps the work out of the living room without giving up a bedroom for it.
Louvers over the garage: two ground-floor garage bays sit behind architectural louvers, so the front of the house is a house, not a pair of garage doors.
- Footprint: 40’ 0” Width x 56’ 0” Depth
- Max Ridge Height: 36’ 9”
- Foundation: Elevated Piling
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 9’ 0” Lower Level | 9’ 0” First Floor | 9’ 0” Second Floor
- Garage: Drive-Under 2-Car Front Entry (975 sq. ft.)
- Roof Details: 4 on 12 Primary / 3 on 12 Secondary Pitch | Truss Framing
Haddie's Hideaway All Suites is drawn so that everyone in the house has a room and a bath of their own, two of the bedrooms are full primaries, and the shared rooms are open enough that everyone still ends up together.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations (most plans; please inquire to confirm)
What's not included
- Architectural or engineering stamp: handled locally if required
- Site plan: handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work): your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations): your subcontractors handle this
- Energy calculations: handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for Chief Architect X17 or Home Designer Pro 2023 or newer
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does Haddie's Hideaway All Suites come with?
Haddie's Hideaway All Suites is drawn on a pier / piling foundation. It is an elevated plan, with the living space raised above open space or parking, drawn for flood zone and coastal lots. A local engineer sizes the foundation for your soil and wind zone.
How tall is Haddie's Hideaway All Suites and how much ground does it cover?
The maximum ridge height is 36' 9". The footprint is 40' 0" x 56' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 2,939 square feet on 2 stories.
What comes in the plan set for Haddie's Hideaway All Suites, and what do I still need locally?
A licensed construction set: cover sheet with general notes, foundation plan, dimensioned floor plans for every level, all four exterior elevations, a cross section, roof plan, electrical plans, and door and window schedules, sold as PDF, PDF plus CAD, or Chief Architect files. Every set is licensed for one build at your build address. An engineer's review and stamp where required, a site plan, engineered floor and roof framing, mechanical and plumbing drawings and energy compliance are produced locally, as they are for any stock plan.
Can I look at Haddie's Hideaway All Suites in detail before buying the full set?
Yes. A $75 study set of Haddie's Hideaway All Suites includes dimensioned floor plans for every level, all four elevations, door and window schedules and a specification sheet, enough to hand a builder for a budget number and to check the footprint against your lot. It is not licensed for construction. The $75 credits in full toward the Haddie's Hideaway All Suites construction set for twelve months.
