The Gray House
Elevated Low Country Cottage | Pier/Piling Foundation
1144 Sq Ft | 2 Bed | 2.5 Bath | 2-Story
430+ Plans Sold · Lowest Price Guaranteed.
Buy direct & save 5% vs. marketplaces. Price match policy →
Licensed for one build at your build address.
Would you like to customize this plan? Request a free modification quote.
The Gray House
2-Bedroom Elevated Low Country Cottage
1,144 SQ. FT. | 2 BED | 2.5 BATH | 2-STORY
The Gray House is a 28 by 28 foot square, stacked three high: a one-car garage at ground level, the living floor above it, and two bedroom suites on top. At 1,144 square feet it is one of the smallest houses we sell, drawn for the lot nothing else fits, a narrow infill lot in town or a slice of beachfront.
The living floor is one open room with an L-shaped kitchen, plus a powder room so guests never go upstairs. Both bedrooms up top have a full bath of their own, and the laundry closet is on that floor with them, where the laundry actually comes from.
Two bedrooms, two full baths: each bedroom upstairs has its own bath, so two couples, or an owner and a tenant, share nothing.
An open living floor: kitchen, living and dining in one room with the kitchen along two walls, and a powder room off it.
Laundry where the laundry is: a laundry closet on the bedroom floor, not two flights down.
A garage and storage underneath: 616 square feet at ground level for one car and the gear.
Standing above the flood line: piers or pilings lift the living floor, which is what makes a 28 foot square work on a coastal lot.
- Footprint: 28’ 0” Width x 28’ 0” Depth
- Max Ridge Height: 33’ 2”
- Foundation: Pier / Piling
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 8’ Lower Level | 9’ Main Living Floor | 8’ Bedroom Level
- Garage: Ground-Floor 1-Car Front Entry (616 sq. ft.)
- Roof Details: 10 on 12 Pitch | Truss Framing
The Gray House stacks parking, living and sleeping on a 28 foot square, and gives up nothing that matters in doing it: two real suites, a full kitchen, a powder room and a dry car.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations (most plans; please inquire to confirm)
What's not included
- Architectural or engineering stamp: handled locally if required
- Site plan: handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work): your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations): your subcontractors handle this
- Energy calculations: handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for Chief Architect X17 or Home Designer Pro 2023 or newer
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does The Gray House come with?
The Gray House is drawn on a pier / piling foundation. It is an elevated plan, with the living space raised above open space or parking, drawn for flood zone and coastal lots. On this page it is offered as pier or piling, chosen before you buy. A local engineer sizes the foundation for your soil and wind zone.
How tall is The Gray House and how much ground does it cover?
The maximum ridge height is 33' 2". The footprint is 28' 0" x 28' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 1,144 square feet on 2 stories.
What comes in the plan set for The Gray House, and what do I still need locally?
A licensed construction set: cover sheet with general notes, foundation plan, dimensioned floor plans for every level, all four exterior elevations, a cross section, roof plan, electrical plans, and door and window schedules, sold as PDF, PDF plus CAD, or Chief Architect files. Every set is licensed for one build at your build address. An engineer's review and stamp where required, a site plan, engineered floor and roof framing, mechanical and plumbing drawings and energy compliance are produced locally, as they are for any stock plan.
Can I look at The Gray House in detail before buying the full set?
Yes. A $75 study set of The Gray House includes dimensioned floor plans for every level, all four elevations, door and window schedules and a specification sheet, enough to hand a builder for a budget number and to check the footprint against your lot. It is not licensed for construction. The $75 credits in full toward the The Gray House construction set for twelve months.
