The Wave II
Single-Level Coastal CottageSlab on Grade
- Heated sq ft
- 1,599
- Bedrooms
- 2
- Baths
- 2.5
- Story
- 1
- Footprint32' × 69'
- Lot needed47 × 114 ft Check your lot
Birthday sale20% off every plan through Nov 2.
- 430+ plans sold
- Sold direct by the designer
- Price match guarantee
- Licensed for one build
The Wave II House Plan
Coastal Cottage House Plan
1,599 SQ. FT. | 2–3 BED | 2.5 BATH | 1-STORY | SLAB ON GRADE
The Wave II is a one-level coastal cottage with a face you remember: a round window above the front porch and wooden brackets under the eaves. It sits on a slab, 32 feet wide, with a big deck out front.
Inside, the plan is open around an oversized island, and sliding doors put the deck a step away from the living room. The primary suite has a four-fixture bath and a walk-in closet, and with everything on one floor there are no stairs to climb.
A round window and brackets: the circular window over the porch and the wooden brackets are what give the cottage its character.
A big front deck: room for a table and chairs and the evening.
An oversized island: the kitchen is arranged around one long island for prep and for company.
Sliding doors to the deck: the living area opens straight onto the deck.
One level: a primary suite with a four-fixture bath and a walk-in closet, and no stairs anywhere.
- Footprint: 32’ 0” Width x 69’ 0” Depth
- Max Ridge Height: 23’ 2”
- Foundation: Slab or Crawlspace
- Framing: 2x6 Exterior Walls | Stick and Truss Roof Framing
- Ceilings: 9’ First Floor
- Roof Details: 9 on 12 Pitch | Stick and Truss Framing
The Wave II shows that a single-level cottage can have real presence: a round window, a deck and an open plan, a house as good to look at as to live in.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Computer Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design, including a decade in custom construction in Charleston, SC, Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations (most plans; please inquire to confirm)
What's not included
- Architectural or engineering stamp: handled locally if required
- Site plan: handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work): your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations): your subcontractors handle this
- Energy calculations: handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for the current version of Chief Architect (X18) or Home Designer 2027
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does The Wave II come with?
The Wave II is drawn on a slab or crawlspace foundation. Slab and crawlspace are both included at no extra charge; choose one under Foundation Options before you buy. A local engineer sizes the foundation for your soil and wind zone.
How tall is The Wave II and how much ground does it cover?
The maximum ridge height is 23' 2". The footprint is 32' 0" x 69' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 1,599 square feet on 1 story.
Check The Wave II against your lot and setbacks →
What comes in the plan set for The Wave II, and what do I still need locally?
A licensed construction set: cover sheet with general notes, foundation plan, dimensioned floor plans for every level, all four exterior elevations, a cross section, roof plan, electrical plans, and door and window schedules, sold as PDF, PDF plus CAD, or Chief Architect files. Every set is licensed for one build at your build address. An engineer's review and stamp where required, a site plan, engineered floor and roof framing, mechanical and plumbing drawings and energy compliance are produced locally, as they are for any stock plan.
Can I look at The Wave II in detail before buying the full set?
Yes. A $75 study set of The Wave II includes dimensioned floor plans for every level, all four elevations, door and window schedules and a specification sheet, enough to hand a builder for a budget number and to check the footprint against your lot. It is not licensed for construction. The $75 credits in full toward the The Wave II construction set for twelve months.
