The Macy
Coastal Contemporary Farmhouse | Elevated Pier/Piling Foundation
2532 Sq Ft | 4 Bed | 4.0 Bath | 2-Story
CAD files not modifiable and are strictly for use by licensed structural engineers. Issued in .dwg format, they are not native AutoCAD files and are not for purposes of altering the original design.
Would you like to customize this plan? Request a free modification quote.
Modify This PlanThe Macy House Plan
Coastal Contemporary House Plan
2,532 SQ. FT. | 4 BED | 4 BATH | 2-STORY | 2-CAR DRIVE UNDER CARPORT
The Macy features a bright, open-concept layout and is designed on an elevated pier or piling foundation, making it a perfect fit for coastal lots all along the coast. The main level. The gourmet kitchen, walk-in butler’s pantry, dining area, and fireplace-warmed living room flow together seamlessly. A dedicated home office sits near the foyer for a quiet workspace, while a large laundry room keeps daily life organized.
The upper level maximizes privacy and independent livability for the entire family. The primary suite serves as a quiet, dedicated owner’s retreat on one side of the floor. On the other side, every single secondary bedroom features its own private en-suite bathroom and walk-in closet — with Bedroom 2 boasting an especially massive walk-in closet. Complete with 349 sq. ft. of covered porches and a built-in elevator connecting all floors, this plan reflects our deep commitment to the way families actually live.
Gourmet Kitchen & Butler’s Pantry: An open kitchen anchored by a central island and a hidden walk-in butler’s pantry, optimized for easy cooking and hosting.
Open Living Area with Fireplace: Seamless flow between the kitchen, dining, and living spaces around a cozy fireplace.
All En-Suite Bedrooms with WICs: Every bedroom includes its own private en-suite bathroom and walk-in closet, highlighted by an oversized walk-in closet in Bedroom 2.
Built-In Home Office: A dedicated main-level workspace complete with a built-in desk, keeping work life organized.
Covered Front & Rear Porches: Offers 349 sq. ft. of dedicated outdoor living designed to capture coastal breezes.
- Footprint: 33’ 0” Width x 59’ 0” Depth
- Max Ridge Height: 34’ 9”
- Foundation: Pier / Piling
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 9’ Lower Level | 9’ First Floor | 9’ Second Floor
- Roof Details: 8 on 12 Primary / 4 on 12 Secondary Pitch | Truss Framing
- Garage: 2-Car Drive Under Carport
Every blueprint in our collection is crafted with a strict focus on structural flow and spatial efficiency. The Macy beautifully merges the warm textures of a contemporary farmhouse with the resilient, elevated requirements of coastal living — proving that luxury entertaining and everyday family practicality can live together seamlessly under one roof.
Angela is a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture. With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes:
- Cover sheet with general notes
- Foundation Plan
- Floor Plans with Dimensions
- Exterior Elevations
- Cross Section
- Door & Window Schedules
- Roof plan
- Electrical Plans
- Cabinetry Elevations (most plans- please inquire to confirm)
What's Not Included:
- Architectural or Engineering Stamp - handled locally if required
- Site Plan - handled locally when required
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
- Energy calculations - handled locally when required
Purchase of Chief Architect plan:
- Plan and Layout files (.plan and .layout) files formatted to be used in design software Chief Architect X15 or Home Designer Pro 2024
- All materials and textures related to plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse Add-On:
- A right reading mirror image of the plan (flipped vertically from right to left) with all dimensions and text formatted to be read correctly
