Little Oak
Elevated Coastal Cottage | Pier/Piling Foundation
1600 Sq Ft | 3 Bed | 2.0 Bath | 2-Story
CAD files not modifiable and are strictly for use by licensed structural engineers. Issued in .dwg format, they are not native AutoCAD files and are not for purposes of altering the original design.
Would you like to customize this plan? Request a free modification quote.
Modify This PlanLittle Oak House Plan
Coastal Elevated Residence
1,600 SQ. FT. | 3 BED | 2 BATH | 2-STORY | 2-CAR DRIVE-UNDER GARAGE
Experience the elevated coastal lifestyle in this stunning 1,600 sq. ft. Little Oak house plan, meticulously designed to balance aesthetic character with structural resilience. Defined by classic board and batten siding and a durable ribbed metal roof, this home provides a sophisticated visual profile. The layout emphasizes seamless flow, featuring an open-concept living space and the convenience of a built-in elevator for multi-level accessibility. The residence is anchored by a spacious primary suite, complete with a high-end 5-fixture bath and a sizable walk-in closet, ensuring a private retreat that prioritizes both comfort and function.
Elevated Coastal Aesthetic: A refined exterior featuring board and batten siding and a ribbed metal roof, blending traditional country style with coastal durability.
Built-In Elevator: Provides seamless accessibility between levels, ideal for aging-in-place or moving groceries and gear with ease.
Primary Suite Luxury: A dedicated primary retreat featuring a 5-fixture bathroom and ample dressing space for a high-end daily experience.
Open-Concept Living: An airy main level designed to maximize natural light and social connectivity between the living and kitchen zones.
High-Capacity Drive-Under Garage: An expansive 1,515 sq. ft. attached garage that provides generous vehicle storage and flexible utility space beneath the main living level.
-
Footprint: 32’ 0” Width x 70’ 0” Depth
-
Max Ridge Height: 33’ 8”
-
Foundation: Pier | Optional Piling (inquire)
-
Framing: 2x6 Exterior Walls | Truss Roof Framing
-
Ceilings: 10’ Lower Level | 9’ First Floor
-
Roof Details: 9 on 12 Primary Pitch
Every blueprint in our collection is crafted with a strict focus on structural flow and spatial efficiency. This residence is designed for those who appreciate the charm of a country home but require the elevated, resilient engineering necessary for coastal terrain—where every square foot is optimized for both lifestyle and longevity.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes:
- Cover sheet with general notes
- Foundation Plan
- Floor Plans with Dimensions
- Exterior Elevations
- Cross Section
- Door & Window Schedules
- Roof plan
- Electrical Plans
- Cabinetry Elevations (most plans- please inquire to confirm)
What's Not Included:
- Architectural or Engineering Stamp - handled locally if required
- Site Plan - handled locally when required
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
- Energy calculations - handled locally when required
Purchase of Chief Architect plan:
- Plan and Layout files (.plan and .layout) files formatted to be used in design software Chief Architect X15 or Home Designer Pro 2024
- All materials and textures related to plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse Add-On:
- A right reading mirror image of the plan (flipped vertically from right to left) with all dimensions and text formatted to be read correctly
