The Cypress
Elevated Low Country | Pier/Piling Foundation
3115 Sq Ft | 4 Bed | 3.5 Bath | 2-Story
CAD files are not modifiable and are strictly for use by licensed structural engineers. Issued in .dwg format, they are not native AutoCAD files and are not for purposes of altering the original design.
Would you like to customize this plan? Request a free modification quote.
The Cypress
4-Bedroom Elevated Low Country Plan
3,115 SQ. FT. | 4 BED | 3.5 BATH | 2-STORY
The Cypress is an expertly crafted 3,115 sq. ft. elevated low country home blueprint that strikes the perfect balance between classic architectural character and refined modern living. A timeless clapboard and board-and-batten exterior profile sets a sophisticated coastal tone, while three distinct outdoor living spaces ensure the landscape is embraced from every angle.
Inside, a dramatic vaulted kitchen anchors the home alongside a secluded, main-floor primary retreat featuring a luxury 5-piece bath. With a built-in elevator, an upper-level private guest suite, and a massive 2,147 sq. ft. drive-under garage, this design offers ultimate coastal utility and style.
Three Outdoor Living Spaces: Multiple covered and open-air porches extend the footprint to capture the best of indoor-outdoor living.
Vaulted Kitchen with Center Island: Soaring vaulted ceilings crown a chef’s kitchen layout complete with an oversized island and walk-in pantry.
Secluded Main-Floor Primary Wing: The master retreat offers absolute privacy, a spa-quality 5-piece bath, and a walk-in closet with custom built-ins.
Dedicated Upper-Level Guest Suite: A private second-floor guest suite with an en-suite bath provides premium comfort and privacy for visitors.
Jack-and-Jill Bedrooms: Two additional upper-level bedrooms share a well-appointed, highly functional Jack-and-Jill bathroom layout.
Integrated Elevator Access: Multi-floor elevator framing ensures effortless movement across this stately elevated design.
- Footprint: 60’ 6” Width x 56’ 6” Depth (Ideal for wide, premium coastal lots)
- Max Ridge Height: 38’ 2”
- Foundation: Coastal-ready Post / Pier
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: Grand 10’ First Floor | 9’ Second Floor
- Garage: Drive-Under 2-Car Side Entry (2,147 sq. ft. total storage space)
- Roof Details: 6 on 12 Pitch | Truss Framing
Every blueprint in our collection is crafted with a strict focus on structural flow and spatial efficiency. The Cypress beautifully layers sprawling outdoor living, open vaulted interior volumes, and a secluded primary suite into a cohesive architectural design that feels both grandly impressive and deeply personal—the hallmark of a truly well-designed custom home.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue and studies in interior architecture.
With 16+ years of custom home design—including a decade in custom construction in Charleston, SC—Angela specializes in resilient coastal style homes engineered for flood and hurricane zones.
Purchase of PDF Set includes:
- Cover sheet with general notes
- Foundation Plan
- Floor Plans with Dimensions
- Exterior Elevations
- Cross Section
- Door & Window Schedules
- Roof plan
- Electrical Plans
- Cabinetry Elevations (most plans- please inquire to confirm)
What's Not Included:
- Architectural or Engineering Stamp - handled locally if required
- Site Plan - handled locally when required
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
- Energy calculations - handled locally when required
Purchase of Chief Architect plan:
- Plan and Layout files (.plan and .layout) files formatted to be used in design software Chief Architect X15 or Home Designer Pro 2024
- All materials and textures related to plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse Add-On:
- A right reading mirror image of the plan (flipped vertically from right to left) with all dimensions and text formatted to be read correctly
