The Holly
Narrow-Lot Beach House | Elevated Pier/Piling Foundation
1495 Sq Ft | 3 Bed | 2.5 Bath | 2-Story
CAD files are not modifiable and are strictly for use by licensed structural engineers. Issued in .dwg format, they are not native AutoCAD files and are not for purposes of altering the original design.
Would you like to customize this plan? Request a free modification quote.
The Holly House Plan
3-Bedroom Narrow-Lot Beach House Plan
1,495 SQ. FT. | 3 BED | 2.5 BATH | 2-STORY | 2-CAR DRIVE-UNDER GARAGE
The Holly is a beautifully designed narrow-lot beach house plan built for the way coastal living actually works — with rearward views, an elevated living level, and a layout that makes every square foot count. An inviting front porch welcomes you in, while a vaulted ceiling over the open living space creates an airy, expansive feel that belies the compact footprint.
The square kitchen island and grill deck are made for social gatherings, while the primary suite offers a private 4-fixture bath and walk-in closet. Two additional bedrooms and a full bath complete the main floor, with a drive-under 2-car garage and patio access at ground level.
Narrow-Lot Optimized Layout: At just 30’ 8” wide, The Holly is engineered specifically for narrow beachfront, coastal, or infill lots with rearward views.
Vaulted Living Room Ceiling: Soaring vaulted ceilings over the open living area create a spacious, airy atmosphere that feels far larger than the footprint.
Square Kitchen Island & Grill Deck: A central kitchen island and adjacent grill deck make this plan a natural entertainer — inside and out.
Primary Suite with 4-Fixture Bath: The master bedroom features a well-appointed 4-fixture bathroom and a generous walk-in closet.
Inviting Front Porch: A welcoming covered front porch sets the coastal tone from the moment you arrive.
Drive-Under 2-Car Garage with Patio Access: Ground-level garage and patio access keep beach gear organized and outdoor living effortless.
- Footprint: 30’ 8” Width x 67’ 4” Depth (Engineered for narrow beachfront and coastal lots)
- Max Ridge Height: 29’ 0”
- Foundation: Piling / Pier
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 9’ First Floor
- Garage: Attached Drive-Under, 1,496 sq. ft., 2 Cars, Front Entry
- Roof Details: 7 on 12 Pitch | Truss Framing
Every blueprint in our collection is crafted with a strict focus on structural flow and spatial efficiency. The Holly proves that a narrow lot is never a limitation — it’s an opportunity to design smarter, stack living spaces vertically, and orient every room toward the view that matters most.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes engineered for flood and hurricane zones.
Purchase of PDF Set includes:
- Cover sheet with general notes
- Foundation Plan
- Floor Plans with Dimensions
- Exterior Elevations
- Cross Section
- Door & Window Schedules
- Roof plan
- Electrical Plans
- Cabinetry Elevations (most plans- please inquire to confirm)
What's Not Included:
- Architectural or Engineering Stamp - handled locally if required
- Site Plan - handled locally when required
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
- Energy calculations - handled locally when required
Purchase of Chief Architect plan:
- Plan and Layout files (.plan and .layout) files formatted to be used in design software Chief Architect X15 or Home Designer Pro 2024
- All materials and textures related to plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse Add-On:
- A right reading mirror image of the plan (flipped vertically from right to left) with all dimensions and text formatted to be read correctly
