Winthrop 35
Craftsman Garage Apartment | ADU with Exterior Porch
980 Sq Ft | 1 Bed | 1.0 Bath | 2-Story
430+ Plans Sold · Lowest Price Guaranteed.
Buy direct & save 5% vs. marketplaces. Price match policy →
Licensed for one build at your build address.
Would you like to customize this plan? Request a free modification quote.
Modify This PlanWinthrop 35 Garage/ADU Plan
1-Bedroom Craftsman Carriage House ADU Plan
980 SQ. FT. | 1 BED | 1 BATH | 2-STORY | 2-CAR GARAGE
The Winthrop 35 is a carriage house with Craftsman detailing and a porch of its own, reached by an exterior stair. Inside, the living, dining and kitchen share one open floor, the kitchen has a U of cabinets with plenty of counter, and the plan allows a few different room arrangements to suit the way it will be used.
A walk-in closet doubles as the laundry room, which keeps the apartment complete without giving up living space. Below, a deep two-car garage of 918 square feet holds the cars and the storage. At 980 square feet it is one of the most complete apartments in our garage plans.
Craftsman outside: the detailing of a small house, so the carriage house looks like it belongs beside the main one.
A porch up the stairs: an exterior stair leads to a porch that belongs to the apartment, a place of its own to sit outside.
Open living, dining and kitchen: one connected room across most of the 980 square feet, bright and easy to furnish.
A U-shaped kitchen: cabinets on three sides, with the counter space and storage of a full kitchen.
A closet that is also the laundry: the walk-in closet holds the washer and dryer too, so the apartment is self-contained; a 918 square foot garage sits below.
- Footprint: 35’ 0” Width x 35’ 0” Depth
- Max Ridge Height: 26’ 11”
- Foundation: Slab on Grade
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 9’ First Floor | 9’ Second Floor
- Garage: Drive-under, 918 sq. ft., 2 Cars, Front Entry
- Roof Details: 10 on 12 Pitch | Truss Framing
The Winthrop 35 is proof that an ADU can have real character: a complete apartment with Craftsman charm that adds value and good looks to the property.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations (most plans; please inquire to confirm)
What's not included
- Architectural or engineering stamp: handled locally if required
- Site plan: handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work): your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations): your subcontractors handle this
- Energy calculations: handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for Chief Architect X17 or Home Designer Pro 2023 or newer
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does Winthrop 35 come with?
Winthrop 35 is drawn on a slab on grade foundation. A local engineer sizes the foundation for your soil and wind zone.
How tall is Winthrop 35 and how much ground does it cover?
The maximum ridge height is 26' 11". The footprint is 35' 0" x 35' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 980 square feet on 2 stories.
