The Quinn Pilings House Plan
Elevated Coastal Country House Plan on Pilings
2,409 SQ. FT. | 3 BED | 3.5 BATH | 2-STORY | 2–3 CAR DRIVE-UNDER CARPORT
The Quinn Pilings is the Quinn lifted onto a piling foundation, so its clapboard exterior, steep metal roof and country rooms can stand on a flood zone or beachfront lot. A large screened porch, a fireplace in the living room and an oversized kitchen island make it as easy for a quiet evening as for a full house.
The primary suite sits apart from the other bedrooms, with a walk-in closet, a five-piece bath and an oversized walk-in shower. Ten-foot ceilings on both the lower and the first floor give every room some height, and the drive-under carport takes two cars or three with a side entry.
A large screened porch: the outdoor room you use most on the coast, screened so the evening is yours and not the mosquitoes'.
A fireplace in the living room: the living room is drawn around it, for the cool evenings the coast still gets.
An oversized kitchen island: a big island in a kitchen with plenty of daylight, where everyone ends up standing.
A five-piece primary bath: two sinks, a tub, an oversized walk-in shower and a toilet, with a walk-in closet off the bedroom.
Ten-foot ceilings on two floors: the lower level and the first floor both have ten-foot walls, and the house stands on pilings above the flood line.
- Footprint: 58’ 0” Width x 64’ 0” Depth
- Max Ridge Height: 37’ 0”
- Foundation: Piling | Optional Pier (+$200)
- Framing: 2x6 Exterior Walls | Truss Roof Framing
- Ceilings: 10’ Lower Level | 10’ First Floor
- Garage: Drive-Under Carport, 2,409 sq. ft., 2–3 Cars, Side Entry
- Roof Details: 10 on 12 Primary / 3 on 12 Secondary Pitch | Truss Framing
The Quinn Pilings brings a Coastal Country house to a lot that has to be elevated. The screened porch, the fireplace and the big island are what make it feel as if it has always been there.
Every blueprint is crafted by Angela, a professional spatial designer with a degree in Construction Graphics Technology from Purdue University and studies in interior architecture.
With 16+ years of custom home design — including a decade in custom construction in Charleston, SC — Angela specializes in resilient coastal style homes designed for flood and hurricane zones.
Purchase of PDF Set includes
- Cover sheet with general notes
- Foundation plan
- Floor plans with dimensions
- Exterior elevations
- Cross section
- Door & window schedules
- Roof plan
- Electrical plans
- Cabinetry elevations (most plans; please inquire to confirm)
What's not included
- Architectural or engineering stamp: handled locally if required
- Site plan: handled locally when required
- Mechanical drawings (location of heating and air equipment and duct work): your subcontractors handle this
- Plumbing drawings (actual pipe sizes and locations): your subcontractors handle this
- Energy calculations: handled locally when required
Purchase of Chief Architect plan
- Plan and layout files (.plan and .layout) formatted for Chief Architect X17 or Home Designer Pro 2023 or newer
- All materials and textures related to the plan for 3D viewing
- PDF plan set included with purchase
Readable Reverse add-on
- A right-reading mirror image of the plan, flipped from right to left, with all dimensions and text still readable
What foundation does The Quinn Pilings come with?
The Quinn Pilings is drawn on a pier / piling foundation. It is an elevated plan, with the living space raised above open space or parking, drawn for flood zone and coastal lots. On this page it is offered as piling or pier (+$200), chosen before you buy. A local engineer sizes the foundation for your soil and wind zone.
How tall is The Quinn Pilings and how much ground does it cover?
The maximum ridge height is 37' 0". The footprint is 58' 0" x 64' 0", which is the number to check against your setbacks; porches and the garage count toward it even though they are not in the heated area. Heated living area is 2,409 square feet on 2 stories.
What comes in the plan set for The Quinn Pilings, and what do I still need locally?
A licensed construction set: cover sheet with general notes, foundation plan, dimensioned floor plans for every level, all four exterior elevations, a cross section, roof plan, electrical plans, and door and window schedules, sold as PDF, PDF plus CAD, or Chief Architect files. Every set is licensed for one build at your build address. An engineer's review and stamp where required, a site plan, engineered floor and roof framing, mechanical and plumbing drawings and energy compliance are produced locally, as they are for any stock plan.
Can I look at The Quinn Pilings in detail before buying the full set?
Yes. A $75 study set of The Quinn Pilings includes dimensioned floor plans for every level, all four elevations, door and window schedules and a specification sheet, enough to hand a builder for a budget number and to check the footprint against your lot. It is not licensed for construction. The $75 credits in full toward the The Quinn Pilings construction set for twelve months.
